Disk includes TIMER.S file with source code:
*timer shell 01.11.90 V.7 Glyn Kendall
*Tabs=10. Case independant.
all equ 0 ;me
HOW_MANY equ 1000 ;call test this many times
*Assemble in devpac using assemble to memory option.
*Then press alt/x to run.
*This prog will call the routine at Test HOW_MANY times.
*When done will wait for 'ESC' then returns to devpac.
bra start jump over test
even
*timed code here
TEST
*this just a demo. Time is 84-86 on my machine
move.l scr(a6),a0
lea 160*16(a0),a0 ;down a bit
lea square(pc),a1 ;data
moveq #31,d0 ;32 hi
.loop move.l (a1)+,(a0)+ ;32 pixels wide
move.l (a1)+,(a0)+
move.l (a1)+,(a0)+
move.l (a1)+,(a0)+
lea 160-16(a0),a0 ;down a scr line
dbf d0,.loop
rts
square
* Hi 32 wide 32
dc.l $00000000,$00000000,$00010001,$00010001
dc.l $00000000,$00000000,$00010001,$00010001
dc.l $00000000,$00000000,$00000001,$00010001
dc.l $00000000,$00000000,$00000001,$00010001
dc.l $00000000,$00000000,$00010000,$00010001
dc.l $00000000,$00000000,$40010000,$7E014001
dc.l $00000000,$00000000,$BE003E00,$C1018001
dc.l $00000000,$00000000,$BF003F00,$C0F90001
dc.l $00F50025,$00EA00DF,$B6F93FF9,$C0000001
dc.l $019F00FF,$01F0010F,$A3013BF9,$CC000001
dc.l $030001FF,$0390020F,$A2803B01,$CC780001
dc.l $061F03FF,$0770040F,$A2783B79,$CC800001
dc.l $0C000780,$0E800800,$A2413B78,$CC800001
dc.l $08000700,$0D000800,$AA593B78,$CC800001
dc.l $08000700,$0D000800,$B6583778,$C8800001
dc.l $07000000,$08000800,$BE783F78,$C0800001
dc.l $1D8F0100,$1E8F1008,$80F90001,$FFF90000
dc.l $091F010F,$1E901010,$FFF9FFF9,$00010000
dc.l $06B8079F,$18201020,$0018FFF9,$00010000
dc.l $07300718,$08270000,$00180009,$FFF10000
dc.l $08330B18,$06270F03,$FFF90008,$FFF1FFE0
dc.l $08330B18,$06270F03,$FFF90008,$FFF1FFE0
dc.l $08330B18,$06270F03,$00F9FF08,$FFF1FFE0
dc.l $08330B18,$06270F03,$01788008,$80F1FFE0
dc.l $08330B18,$06270F03,$01788008,$80F1C1E0
dc.l $08330B18,$06270F03,$01788008,$80F1C1E0
dc.l $08330B18,$06270F03,$01798009,$80F0C1E0
dc.l $08330B18,$06270F03,$01798009,$80F0C1E0
dc.l $08330B18,$06270F03,$01798009,$80F0C1E0
dc.l $08330B18,$06270F03,$01788009,$80F0C1E0
dc.l $00000000,$00000000,$00000001,$00000000
dc.l $1C73FC0F,$03FF0000,$33320F0F,$00FEFFFE
*this just a demo end
****************************
Start move.l a7,a5
lea spdata(pc),a6 Global data pointer
lea datae+300(a6),sp my stack pointer
move.l 4(a5),a5 base page
move.l $c(a5),d0 text
add.l $14(a5),d0 data
add.l $1c(a5),d0 bss
add.l #$100+300,d0 base page length+stack space
move.l d0,-(sp) length to keep
move.l a5,-(sp) start address
clr.w -(sp) filler
move.w #$4a,-(sp)
trap #1 M_SHRINK
lea 12(sp),sp
*program here
bsr init
bsr cls
bsr gotime init timer
move.w #how_many-1,d0 call sub this many
tm_lp move.w d0,-(sp)
bsr test timed sub
* bsr getime
move.w (sp)+,d0
dbf d0,tm_lp
bsr ttime print result
t_w bsr keys wait esc
bra.s t_w
Cls move.l scr(a6),a0
move.w #7999,d0
.loop clr.l (a0)+
dbf d0,.loop
rts
Gotime lea ntime(pc),a0
clr.w (a0)
bsr.s gtime
lea stime(pc),a0
move.w clk(pc),(a0)
rts
Getime bsr.s gtime
move.w clk(pc),d0
lea ntime(pc),a0
sub.w (a0),d0
add.w d0,(a0)
bra sprint
Ttime bsr.s gtime
move.w clk(pc),d0
sub.w stime(pc),d0
bra sprint
Gtime pea rtime(pc)
move.w #38,-(sp)
trap #14
addq.l #6,sp
rts
rtime lea clk(pc),a0
move.w $4bc.w,(a0)
rts
clk ds.w 1
stime ds.w 1 start time
ntime ds.w 1 now time
KEYS moveq #0,d7
ke_lp move.l d0,d7 empty buffer
move.w #$ff,-(sp)
move.w #6,-(sp) crawio
trap #1
addq.l #4,sp
tst.l d0
bne.s ke_lp
move.l d7,d0 last valid key
cmpi.w #$1b,d0 esc?
beq quit
* cmpi.b #32,d0 space bar(fire)
* beq.s fire
swap d0 cursors in high word
cmpi.w #$48,d0
beq.s uparrow
cmpi.w #$50,d0
beq.s dnarrow
cmpi.w #$4d,d0
beq.s rtarrow
cmpi.w #$4b,d0
beq.s ltarrow
k_ex rts
UPARROW subq.w #1,y(a6)
up_x rts
DNARROW addq.w #1,y(a6)
dn_x rts
RTARROW addq.w #1,x(a6)
rt_x rts
LTARROW subq.w #1,x(a6)
lt_x rts
INIT move.l #32260,-(sp) 32000+enough to ensure 256.b align
move.w #$48,-(sp) malloc
trap #1
addq.l #6,sp
tst.l d0 error?
beq quit must have it
move.l d0,ram(a6) for return to system at end
add.l #256,d0 align
andi.w #$ff00,d0 long value really
move.l d0,scr2(a6)
move.w #2,-(sp) get_physbase
trap #14
addq.l #2,sp
move.l d0,scr1(a6)
move.l d0,scr(a6)
move.w #4,-(sp) get_rez
trap #14
addq.l #2,sp
move.w d0,rez(a6)
cmpi.w #2,d0 is it hi
beq.s in_0
moveq #0,d0
bsr.s dorez golow
bsr getcol get system colours
bsr putcol put sprite colours in
in_0 move.w #-1,-(sp)
move.w #-1,-(sp)
move.w #35,-(sp) read keyboard rates
trap #14
addq.l #6,sp
move.w d0,d1
andi.w #7,d1
move.w d1,rep(a6)
lsr.w #8,d0
move.w d0,ini(a6)
move.w #2,-(sp) repeat
move.w #1,-(sp) set kbd rate
move.w #35,-(sp)
trap #14
addq.l #6,sp
move.w a0,seed(a6) just put a number in
pea stmsg(pc) do cursor,colors
move.w #9,-(sp)
trap #1
addq.l #6,sp
rts
dorez move.w d0,-(sp)
move.l #-1,-(sp)
move.l #-1,-(sp)
move.w #5,-(sp)
trap #14
lea 12(sp),sp
rts
QUIT move.l ram(a6),-(sp) return memory to system
move.w #$49,-(sp)
trap #1
addq.l #6,sp
move.w #-1,-(sp) don't change rez
move.l scr1(a6),-(sp) physical screen 1
move.l scr1(a6),-(sp) logical screen 1
move.w #5,-(sp) setsceen
trap #14
lea 12(sp),sp
bsr outcol return colours
cmpi.w #2,rez(a6) hi rez?
beq.s qu_1 no
moveq #1,d0
bsr.s dorez gomed
qu_1 move.w rep(a6),-(sp)
move.w ini(a6),-(sp)
move.w #35,-(sp)
trap #14 keyboard rates
addq.l #6,sp
move.w #27,-(sp) show cursor (esc e)
move.w #2,-(sp)
trap #1
addq.l #4,sp
move.w #'e',-(sp) show cursor
move.w #2,-(sp)
trap #1
addq.l #4,sp
ke move.w #$ff,-(sp) empty keyboard buff
move.w #6,-(sp) crawio
trap #1
addq.l #4,sp
tst.l d0
bne.s ke
clr.w -(sp) Exit to desktop
move.w #$4c,-(sp)
trap #1
*set the screen to scr1 and the logical(system print) to scr2
SSCR1 move.w #37,-(sp) vsync
trap #14
addq.l #2,sp
move.w #-1,-(sp) don't change rez
move.l scr1(a6),-(sp) physical screen 1
move.l #-1,-(sp) scr2(a6),-(sp) logical screen 2
move.w #5,-(sp) setsceen
trap #14
lea 12(sp),sp
move.w #14,wscr(a6) 14=scr1 0=scr2
move.l scr2(a6),scr(a6) sprite write
move.w #37,-(sp) vsync
trap #14
addq.l #2,sp
rts
SSCR2 move.w #37,-(sp) vsync
trap #14
addq.l #2,sp
move.w #-1,-(sp) don't change rez
move.l scr2(a6),-(sp) physical screen 2
move.l #-1,-(sp) scr1(a6),-(sp) logical screen 1
move.w #5,-(sp) setsceen
trap #14
lea 12(sp),sp
move.w #0,wscr(a6) save scr num(use other screen)
move.l scr1(a6),scr(a6) sprite write to other screen
move.w #37,-(sp) vsync
trap #14
addq.l #2,sp
rts
*wait d4+1 interupts
DELAY move.w #37,-(sp) vsync
trap #14
addq.l #2,sp
dbf d4,delay
rts
PRINT bsr.s setlog1
bsr.s pr_in
bsr.s setlog2
pr_in move.w #27,-(sp) home (esc H)
move.w #2,-(sp)
trap #1
addq.l #4,sp
move.w #'H',-(sp) home
move.w #2,-(sp)
trap #1
addq.l #4,sp
pea msg(pc)
move.w #9,-(sp)
trap #1
addq.l #6,sp
rts
SETLOG1 move.w #-1,-(sp) don't change rez
move.l #-1,-(sp) or physical
move.l scr1(a6),-(sp) logical screen 1
move.w #5,-(sp) setsceen
trap #14
lea 12(sp),sp
rts
SETLOG2 move.w #-1,-(sp) don't change rez
move.l #-1,-(sp) or physical
move.l scr2(a6),-(sp) logical screen 2
move.w #5,-(sp) setsceen
trap #14
lea 12(sp),sp
rts
;D0.W =VALUE RANGE IS 0 TO 65535 THEN WILL RET VAL - 65535
;WILL PRODUCE LEADING ZEROS FOR ALL VAL<10000 USES D0-D3 A0-A2
sprint LEA.L STRING(PC),A0
LEA.L TENT(PC),A1
LEA.L DIGIT(PC),A2
MOVEQ #3,D3 ;4 FOR 10000
AGAIN MOVEQ #0,D1
MOVE.W D0,D1
DIVU (A1)+,D1
BEQ.S NOSUB
MOVE.W D1,D2
MULU -2(A1),D2
SUB.W D2,D0
NOSUB MOVE.B 0(A2,D1.W),(A0)+
DBF D3,AGAIN
SWAP D1
MOVE.B 0(A2,D1.W),(A0)+
sf (a0) msg end
bsr.s setlog1
bsr.s spr_in
bsr.s setlog2
spr_in pea scmsg(pc)
move.w #9,-(sp)
trap #1
addq.l #6,sp
RTS
TENT DC.W 10000,1000,100,10 ;SET UP FOR 10000 MAX
DIGIT DC.B '0123456789'
scmsg dc.b 27,'H'
STRING DS.W 3
*get the system colours
GETCOL lea syscol(pc),a4
moveq #0,d4 16.w
sy_lp move.w #-1,-(sp)
move.w d4,-(sp) colornum
move.w #7,-(sp)
trap #14
addq.l #6,sp
move.w d0,(a4)+
addq.w #1,d4
cmpi.w #16,d4
bne.s sy_lp
rts
*either return colors to system or put a new set in
PUTCOL lea spcol(pc),a4 set sprite colours
bra.s sysin
OUTCOL lea syscol(pc),a4
sysin moveq #0,d4 16.w
sy_l move.w (a4)+,-(sp)
move.w d4,-(sp) colornum
move.w #7,-(sp)
trap #14
addq.l #6,sp
addq.w #1,d4
cmpi.w #16,d4
bne.s sy_l
rts
*word rnd in d0
RND move.w seed(a6),d0
mulu #1509,d0
add.w #41,d0
move.w d0,seed(a6)
rts
*
*data
msg dc.b ' Score',0
even
stmsg dc.b 27,'f',27,'b',15,27,'c',6,0 hide cur,foreg,backg color
even
syscol ds.w 16 * Colour palette
spcol
dc.w $0000,$0001,$0776,$0554,$0332,$0221,$0760,$0640
dc.w $0610,$0400,$0046,$0125,$0223,$0334,$0556,$0007
*
*BSS
*spdata
*global data
rsreset
x rs.w 1
y rs.w 1
backload rs.l 1
rep rs.w 1 kbd repeat rate
ini rs.w 1 kbd initial rate
scr rs.l 1 current screen address
scr1 rs.l 1 screen1 address
scr2 rs.l 1 screen2 address
wscr rs.w 1 which scr 1(=0) or 2(4) is current
rez rs.w 1 scr resolution 0=lo 1=med 2=hi
ram rs.l 1 scr2 ram from system
seed rs.w 1 rnd seed
score rs.w 1 game score
pybit rs.w 1
ydis rs.w 1
datae rs.w 0 end of relative data
spdata ds.b __RS Devpac command to reserve bss storage
end
