### Information - Crystal Atari Browser (CAB)

Language[unknown]PublisherST Format
Developer[n/a]DistributorFuture Publishing
ControlsMouseCountry
Box / InstructionsEnglish, GermanSoftwareEnglish
Programmer(s)

## Clauss, Alexander

SerialST TypeST, STe, TT, Falcon030 / 0.5MB
ResolutionMedium / HighNumber of Disks1 / Double-Sided / HD Installable
Protection

 Other version with the same title: ST Format (version 1.1) ().

### Instructions - Crystal Atari Browser (CAB)

 CAB (HTML-Browser) for Atari ST/TT/Falcon/Medusa/Eagle/MagicMAC --------------------------------------------------------------------- Version: 0.98ž (September 1995) CAB - taxi to the information highway CAB - Crystal Atari Browser This browser is capable of reading HTML format documents. The HTML documents could be on disk or CD. Reading pages on-line to an Internet World Wide Web (WWW) sites requires a separate module. Distribution ------------ CAB (HTML-Browser) is FREEWARE. It may be copied and used freely. Distribution by BBSs and PD libraries is allowed. However, CAB (HTML- Browser) may NOT under ANY circumstances be included in CD-ROM collections or on magazine cover disks without my prior written permission. CAB (HTML-Browser) and its documentation must always remain together and complete with all its files and documentation. Changes to the program and/or documentation is forbidden. If you like CAB (HTML-Browser) and you use it regularly, please register your copy, any currency is welcome. A glance at the version number should tell you this program is still at an early stage of development so if you would like to see this program developed please send some feedback and register your copy. UK, USA users can take advantage of local support, refer to SUPPORT.TXT for more details. No feedback means no development, it's that simple! My address: Alexander Clauss Stresemannstr. 44 D-64297 Darmstadt Germany UK support: Joe Connor 65 Mill Road Colchester CO4 5LJ England USA support: Jeff Wisniewski P.O. Box 1243 Newtown, PA 18940-0871 USA Email contacts: Author: Alexander Clauss: aclauss@rbg.informatik.th-darmstadt.de UK support: Joe Connor: jconnor@cix.compulink.co.uk USA support: Jeff Wisniewski: jeffrey.wisniewski@microserve.com Original translation: Ben Bell: bjb@bigbox.demon.co.uk Installation ============ The CAB distribution is supplied ready to run once unarchived onto your working disk. To take advantage of the creature comforts offered by CAB (HTML-Browser) follow the steps below to set up your working environment. CAB (HTML-Browser) can be used as either a desktop accessory or a normal GEM application. To install as a desktop accessory rename CAB.APP to CAB.ACC and place it and CAB.RSC in the root directory of your boot drive. HTML files downloaded from WWW sites often include long filenames which can easily result in duplication of filenames using the basic TOS 8+3 character file system. It's well worth setting up a Minix hard disk partition or other file system which supports long filenames to handle HTML files. 1) Install fonts (Dialog: Options/Font selection) ------------------------------------------------- Wherever possible CAB (HTML-Browser) uses different fonts and point sizes to display HTML files. Optimal output quality is provided using vector fonts for which you'll need to install either NVDI v3.x or SpeedoGDOS. Normal bitmap fonts can be used but they're not nearly as nice. Next you need to tell CAB (HTML-Browser) which (GDOS) fonts to use for each corresponding style in an HTML document. Vector fonts as provided by SpeedoGDOS or NVDI 3.x are recommended. You must specify three fonts (sans-serif, serif and monospaced) in four different styles (normal, bold, italic and bold and italic) making twelve selections altogether. For the bold and italic settings you should use a 'real' bold or italic font wherever possible. If you don't have one available you'll have to simulate these text effects using the corresponding buttons adjacent to the font selection popup. If you're using vector fonts then use the appropriate font from the font family, if available. The supplied INF file has the following presets (for NVDI 3.x): Headings: Swiss 721 (normal, bold, italic, bold+italic) Normal text: Dutch 801 (normal, bold, italic, bold+italic) Formatted: Letter Gothic 12 Pitch (normal, bold, italic, bold+italic) If you don't like or haven't got these fonts, you'll have to select alternatives. The size of the body text can also be altered. Don't make this too large or too small! Somewhere between 10 and 13 point is sensible (I use 12 point). If you haven't got access to vector fonts (i.e. you don't own a copy of NVDI 3.x or SpeedoGDOS) then the point size won't change, but the text can still be viewed using the system font, usually 10 point. 2) External viewers (Dialog: Options/External programs) -------------------------------------------------------- If a link in an HTML document points to a file which is not in HTML format, an external viewer can be called. These programs can be called in one of two ways and are configurable via the 'External programs...' dialog via the 'Options' menu. Individual file types can be assigned to different programs. File extensions are entered into the 'FILES' field. Several extensions can be entered using a comma to separate each entry. Programs are selected by clicking on the selection box to the right of the 'FILES' field which displays the file selector to select the desired viewer. Finally each entry includes a 'Supports VA_START' checkbox which should be crossed if the viewer understands the VA_START message so CAB can send a VA_START message to the viewer so the file can be viewed with re-launching the viewer. The 'DEFAULT' program (*.*) is called to display any files for which no program has been assigned. If one of more extensions have been defined without a program assigned CAB attempts to display the file. This is only sensible for '*.gif', '*.xbm', '*.htm' and ASCII files (for example: *.txt, *.doc, *.c, *.pas, *.tex etc...) for which CAB (HTML-Browser) includes built-in display routines. Using CAB (HTML-Browser) for these file types does keep the number of external viewers needed to the minimum. The current HTML page can be displayed as source text by selecting an application in the 'SOURCE' entry. This application is called via the menu entry 'Source text...'. If no application has been assigned the 'DEFAULT' program is called instead. Some suggested external programs: --------------------------------- *.text,txt : ST-Guide, 1st-Guide (or none, then HTML.APP is used) *.mpeg,mpg,mpe : 1st-Guide (on a Falcon under Single TOS the fast DSP MPEG player is recommeded) *.jpeg,jpg,jpe : 1st-Guide, GEMview *.tiff,tif : GEMview, Imagecopy *.gif,xbm : GEMview, Imagecopy (or none, then HTML.APP is used) *.dvi : DVI display included in TeX archives *.* (Default) : GEMview (or other program which handles as many formats as possible) *.html,htm : ST-Guide, 1st-Guide, (or and editor so the HTML source can be edited) 3) Paths (Dialog: Options/Paths...) ---------------------------------- If you have a copy of the c't ROM '94 (CD containing the contents of the German magazine c't) then set the path for the field 'c't CDROM'. In the 'HTML folder' field set the directory which contains the file DEFAULT.HTM on the CD (eg ?:\HTML\, where ? is replaced with the drive letter of your CD-ROM drive). In the 'DATABASE' field set the path to the contents of the CD (?:\UNIX\CT94.DAT, again ? is the CD-ROM drive letter). If you want to use CAB online to an Internet WWW site you should set the 'Cache folder' where all files downloaded from the Internet can be stored. Ideally this folder should be on a Minix hard disk partition, or other file system which supports long filenames to handle HTML files because HTML files downloaded from WWW sites often include long filenames which can easily result in duplication of filenames using the basic TOS 8+3 character file system -and make sure the partition has plenty of room! In 'HTML folders' you can enter the paths CAB (HTML-Browser) looks to find HTML files. HTML files contain absolute local paths (eg /path/file.html) which can soon turn the root directory of your partition into choas. The HTML folders help avoid this by telling HTML-Browser to look for HTML files in the folders specified. Here's an example: Entered HTML folders: F:\HTML.DOC\ G:\VARIOUS\ Current drive: F:\ Path in HTML file: /example/text/index.html Where CAB looks: 1) F:\example\text\index.html 2) F:\HTML.DOC\example\text\index.html 3) G:\VARIOUS\example\text\index.html 4) Cache (Dialog: Options/Cache...) ----------------------------------- CAB (HTML-Browser) uses two caches to maximise the display of files. The 'Image cache' is used to avoid repeated unpacking and dithering which both take a great deal of processing time. Images no longer displayed are held in memory (RAM) in case they are needed again. Naturally this takes memory so the maximum size of the cache can be set in the 'Maximum size' field. If the cache becomes full the least used image is purged from the cache to free up more space. Using the 'Keep free' option it's also possible to set the minimim amount of memory free for other applications. The cache can also be manually purged using the 'Free cache' button which can be useful to quickly free up more memory for another application under a multitasking OS. The cache remains empty until further images are displayed in CAB (HTML-Browser). The 'Internet Cache' is used to store files downloaded from the Internet on your disk to avoid repeatedly downloading the same files from the Internet if they're viewed more than once. See also 'Paths' The 'Maximum size' and 'Keep free' options limit the amount of disk space used by the cache and CAB (HTML-Browser) will purge the oldest files from the cache to maintain the cache within the defined limits. If the 'Delete after 'quit'' option is active (crossed) the files in the cache will be deleted on exiting CAB (HTML-Browser). Naturally unless disk space is limited or you're sure you'll never need the files again it's best to keep the files. The 'Free cache' button is for emergency use in case you need extra disk space fast! Only files placed in the the cache directory placed there by CAB (HTML-Browser) will be deleted. 5) Display (Dialog: Options/Display) ------------------------------------ In this dialog you can configure various display options for HTML documents. Colours: This section allows you to configure the display colours, for the foreground text, the background colour and link colour. If you're using less than 16 colours, the window background will always be white regardless of the settings here. In 16 colour mode, only the first nine colours should be used as the last 7 may be changed for pictures etc. In more than 16 colours, any of the first 16 can be used as they will not be changed. Links: Links can be displayed in underlined and/or bold text (this is important for monochrome systems who can't distinguish links by colour). Images: Controls image display. 'Don't show' Prevents images being loaded and displayed which speeds up page loading. 'Monochrome' Images are displayed in monochrome using dithering. It's the quickest method but this obviously the quality suffers. 'Greyscale' Images are displayed as greyscales. Higher quality display at the expense of speed. 'Colour' Images are displayed in colour depending on the hardware available: - 4-8 bitplanes (16-256 colours). Images are dithered if the number of colours available is less than the number of colours contained in the image. In 16 colour modes greyscale display is often more suitable. - 15/16 bit-high-colour (32768/65536 colours) eg Falcon True color mode - 24 or 32 bit-true-colour (16.7 million colours) 'Text instead of images' The HTML language provides for text-only systems by allowing images to be accompanied by some text which is displayed instead of the image. This enables WWW Browsers which cannot display images to display text output instead. If this option is active (crossed) only images for which no alternative text is available are displayed as images. Text width: Text can either be formatted at a fixed width or justified to fit the window width. Text justified to fit the window width looks better but takes longer to display as the text must be reformatted. 6) Internet module ------------------ To browse WWW pages on-line to the Internet a further module (CAB.OVL) is needed. This module should be copied to the same directory as CAB.APP. This file contains the additional routines needed to access the Internet. On Minix partitions the x-flag of the CAB.OVL file must be set otherwise the modul can not be started. Installation is now complete, now is a good time to save your setup (Options/Save options). Using CAB (HTML-Browser) ------------------------ All the functions of the program that are controlled by the menu bar can also be accessed by a popup menu. This menu is brought up by clicking the left mouse button on the viewer window (not on a link). This is essential for desk accessories which can't install their own menu bars. Navigating HTML Documents ------------------------- Click on any underlined keyword to branch to the new page. Press the [Undo] key to step to return to the previous page. Clicking on a link using the right mouse button will display the address of the page it links to. Home Page (Menu entry: Navigate/Home page) ------------------------------------------ This menu item will display the standard home page, home.html On starting CAB (HTML-Browser) it tries to load the file 'home.html' (i.e. 'home.HTM' on TOS file system). Any HTML format file could be set up as your home page and its contents could be set up to point at other HTML documents as required. Find keyword... (Menu entry: Navigate/find keyword) --------------------------------------------------- This allows the user to perform a search for keywords in HTML files, and can optionally be case sensitive. The search can be conducted over one of the following ranges of documents: 1) Current document only. The text is searched for in the current document (the top window). If the text is found the window is scrolled so the text is displayed at the top of the window. 2) Local HTML Documents. The text is searched for in all local HTML documents contained in the paths specified in the 'Paths' dialog box (and their subdirectories). The files that contain the text is made into a list of links in an HTML file called 'result.html'. At the moment the HTML files searched by method two are searched purely as text, so hidden text such as comments, HTML commands, links and so are also found. Processing the files to ignore hidden text would be very time costly. This also means that special characters such as accents and so on which are written into HTML code using commands like 'ä' are not found. This shortcoming may be addressed in a future version. Another tip: If you're searching for something which is often used in HTML code as a command or URL-address placing a space before it may make it less likely to turn up in commands or URL addresses.. For example: Searching for the text 'WWW' often matches subdirectories and addresses for pages in the form '.../WWW/foo.html...'. Placing a space before it in the search string, ' WWW' removes these occurences resulting in a better targetted search. These don't apply to methods 1) and 3)! 3) In the c't-CDROM Database. This option is only useful for people with the c't-CDROM (the 1994 c't magazines in HTML format)! In this case the HTML files themselves aren't searched, but the index file on the CD is accessed instead. So that HTML-Browser knows where the files for this CD are kept are, you need to fill in the appropriate section of the 'Paths' dialog box - the HTML documents (in \HTML which also contains the file DEFAULT.HTML) and the index database (\UNIX\CT94.DAT). As in the previous method, matching documents are made into an HTML document called results.html which is then opened. Hotlist (Menu entry: Navigate/Hotlist...) ----------------------------------------- The hotlist is a list of your most used HTML documents. This list enables you to get quickly to you favourite pages, without having to navigate through a long series of pages to get there. To place a page in the hotlist, select 'Document -> Hotlist'. Selecting 'Hotlist' displays a dialog containing the page hotlist. The button "Add" adds the current page to the hotlist. Double click on an entry or select it then press 'Open' opens the selected page. 'Delete' removes the page from the hotlist, and 'Change' allows the page title to be edited and view the filename of the page it points to. Selecting an HTML document ========================== The 'Open HTML document' option in the 'File' menu calls the file selector which can be used to open any HTML document from hard disk or CD-ROM. Any file types can be selected. HTML, XBM and GIF files are normally displayed by CAB (HTML-Browser) with other file types handled by external programs. Refer to 'External programs' for more details. If a folder is selected the contents of the folder and sub directories are displayed graphically as an HTML page and any files and folders can be selected using the mouse! The 'Open URL...' option in the 'File' menu displays the URL dialog containing any URL (Universal Resource Locator) addresses you have set up to access the WWW. Technical ========= CAB (HTML-Browser) understands most of the HTML2 specification. Currently the form and entry functions are not implemented. Transparent colour images are displayed, where available. Multi-user installation: If the environmental variable $HOME exists the specified path is searched for the configuration files i.e. the Hotlist and home.html. If$HOME isn't set, or the files are not available in the \$HOME path shel_find() is used to locate the files. CAB.OVL Module for on-line Internet access ------------------------------------------- I'm not able to test an Internet module but have built an interface into CAB (HTML-Browser) to enable anyone capable of programming these routines to create an on-line module. The description of this interface is provided as commented C code and uncommented Pascal source in the 'module' folder in this distribution. I would be pleased if anyone who programs an on-line module would let me have a copy for inclusion with CAB (HTML-Browser)... Thanks! ======= I'd like to thank everyone who through their praise, criticism, suggestions and bug reports have helped in the development of CAB (HTML-Browser). In particular the follwoing people deserve a mention: Ben Bell Stephane Boisson Joe Connor Dieter Fiebelkorn Tim Newsome Fred Nicklisch Jeff Wisniewski Possible future updates ----------------------- -Support for the HTML3 specification (tables, forumlae, etc.) -Better font setup and handling of bitmap fonts Please feel free to make further suggestions and constructive criticisms... History ======= V0.8ž 20.04.1995 First release version V0.9ž 15.05.1995 -Reduced memory requirements -MTOS Drag&Drop (ARGS) supported -External programs will now run under singleTOS -Error reports are now more descriptive -Bugfix: when running as an accessory no longer tries to invert (non-existant) menu items -The .INF file is now found even if HTML is not started in it own directory -Is now a lot more tolerant of buggy HTML file syntax. -home.html is now loaded on startup if possible -Hotlist -Configuration of window and text colours etc. -Search (including searching c't CDROM) -In-line images can be displayed as greyscales V0.93ž 07.06.1995 - Preparation for on-line operation implemented (although not activated in this version) - Bugfix: Problem with line spacing fixed - Bugfix: Endless loop with defective gifs fixed - Bugfix: fclose() for Hotlist was forgotton :-( - A few other minor bugfixes V0.94ž 07.07.1995 - Bugfix: Deleting the last Hotlist entry caused a crash :-( - Bugfix: CR/LF inside tags led to problems - Bugfix: Last word in an HTML file gobbled - Documents access using absolute path information, including directories listed in the 'Paths...' dialog - Contents of a drive can be displayed as an HTML document (including launching programs and viewing files)! - Support for the special Netscape tags V0.95ž 04.08.1995 - Inline colour images - Configurable image cache (in RAM) - Configurable WWW cache (on disk) - Option to automatically format text to the window width - ASCII, xbm and gif files can now be viewed directly in HTML-Browser. Calling external programs is no longer required (but naturally still available as an option) - Interface for 'Internet module' implemented Using a suitable module HTML-Browser could be used to display WWW pages on-line to the Internet, naturally you'd need an Internet account to do this! - Support for xbm images EOF
